Designing Single- and Three-Axis Selfie Sticks With MSPM0 MCUs

There are two main types of selfie stick products on the market: single-axis selfie sticks and three-axis selfie sticks. How can a selfie stick maintain the shooting stability of a mobile phone? Hand shaking of photographers can cause one-axis or three-axis jitter, in which the position and direction is detected by the built-in gyroscope sensor of the selfie stick. The internal MCU can process the data and drive one or three motors to produce the opposite movement, which is used to offset the vibration of the mobile phone screen and stabilize the phone when taking a picture or video.

Figure 1 3-Axis Selfie Stick

To sense, process, and actuate the single- or three-axis motors in a gimbal or selfie stick application, TI’s MSPM0 MCUs can meet the requirements with high-performance features, portfolio, and diverse package sizes to fit small form factors.

Figure 2 3-Axis and 1-Axis Selfie Stick Block Diagram

Hardware and software

Hardware

Microcontroller (MCU): Acquires gyroscope or accelerator information, runs the control algorithms generates the PWM, and gets the motor speed and position information.
Driver: BLDC integrated MOSFET motor driver
Power system: Battery, battery charger, boost, and LDO regulator

Software

Application: Task management and scheduling.
Algorithm: Calculates the gesture of phone in real time according gyroscope or accelerometer feedback; drives BLDC motor using Hall-sensored trapezoidal or sensorless algorithm to achieve closed-loop position control.

All these functions can be realized using TI devices:

MCU
- MSPM0Lxx ARM Cortex M0+ 32-MHz MCUs
- MSPM0Gxx ARM Cortex M0+ 80-MHz MCUs
BLDC Motor Driver: 3-phase BLDC Motor Driver (DRV831x series)
Charger: Battery charger ICs (BQ series)
Boost: Step-up (boost) switching regulators series
LDO: LDO linear regulators series

Why is MSPM0 considered for selfie sticks?

The newest Arm® Cortex® M0+ MSPM0Gx high-performance MCUs feature up to 80-MHz operating frequency, 32 kB to 128 kB flash options, scalable analog integration, advanced on-chip motor control peripherals provide a design for various selfie stick applications.

What can MSPM0 do in a selfie stick?

The following resources are available for selfie sticks:

Motor control designs in MSPM0-SDK
- MSPM0 Sensored Trap Library
  - Supports DRV831x devices with integrated current sense
- MSPM0 Sensorless FOC Library
  - Supports DRV831x devices with integrated current sense
High-performance core integrated math accelerator (MATHACL)
- Reduce process time for FOC and gesture estimation algorithms and sensing signal
Analog and digital peripherals for motor control
- Two independent 4-Msps 12-bit ADC modules: fast and accurate current sensing
- Two zero-drift chopper op-amps: accurately amplify the 2-phase current
- Three high speed comparators: enable hardware current limiting
- Advanced motor control timers: six flexible PWMs and cross triggers
Communication interfaces
- SPI, UART, and I2C to connect to IMU (inertial measurement unit) sensor

Figure 3 Selfie Stick System Block Diagram Based on MSPM0Gx

Resources

Order an MSPM0 LaunchPad™ development kit and DRV8316REVM today to start evaluating MSPM0 for a motor control function for a gimbal or selfie stick system. Jump-start a design with MSPM0 code examples and interactive online trainings. The follow links provide resources that are available.

MSPM0-SDK
MSPM0 overview page
MSPM0 Academy
MSPM0 LaunchPad development kit
- LP-MSPM0L1306
- LP-MSPM0G3507
DRV831xEVM
MSPM0 Trapezoidal Control Application Note
MSPM0 Sensorless FOC Application Note
TI Precision Labs - Motor Drivers: Brushless-DC Basics
